Listening to FM/AM broadcasts

Press TUNER to select the reception band.

FM:

When listening to an FM broadcast.

AM:

When listening to an AM broadcast.
Use TUNE kurosankaku Sankaku-Reverse to select the station you want listen to.

When a station is received, the Icon Tuned 3 indicator lights.

The ST indicator lights up when a stereo broadcast is received.
