Specifications

Network type:

Conforming to IEEE 802.11a/b/g/n/ac

Used frequency range:

2.4 GHz, 5 GHz

Communications system:

Bluetooth Version 5.4

Transmission power:

Power Class 1

Maximum communication range:

Approx. 98.4 ft/30 m in line of sight *

Used frequency range:

2.4 GHz band

Modulation scheme:

FHSS (Frequency-Hopping Spread Spectrum)

Supported profiles:

A2DP, AVRCP

Corresponding codec:

SBC

Transmission range (A2DP):

20 Hz – 20,000 Hz

Operating temperature:

41 °F - 95 °F (5 °C - 35 °C)

Power supply:

AC 100 – 240 V, 50/60 Hz (for Europe model)
AC 100 – 120 V, 50/60 Hz (for North America model)

Power consumption:

37 W

Power consumption in Network Standby Mode:
(Voice service activated)

4.0 W (Wi-Fi 2.4 GHz)
4.1 W (Wi-Fi 5 GHz)
3.6 W (Ethernet)
4.1 W (USB with Wi-Fi)
3.5 W (Bluetooth)

Power consumption in Deep Standby Mode:

0.4 W

Max Analog Input:

2 Vrms
