Back panel

HEOS_HS2_Back Panel

Power Input (DC IN)

Used to connect the external power supply link.

Bluetooth Button ( Button Bluetooth )

Used in the Bluetooth pairing settings link.

AUX Input (AUX IN)

Used to connect audio devices link.

Used to add the speaker to your wireless network link.

USB port

Used to connect USB storage devices.

Network Connector (NETWORK)

Used to connect this unit to a wired Ethernet network link.

Connect Button (CONNECT)

Used for Wi-Fi setup link.

Connect in Status LED

Indicates the status of this unit link.
