Specifications

Power amplifier Rated output:

2-channel driving
100 W+100 W (6 Ω/ohms, 1 kHz, T.H.D. 0.7 %)

Output connectors:

4 – 16 Ω/ohms

THD+N:

ANALOG IN: 0.1 %(1 kHz)

S/N ratio (10 W, 6 Ω/ohms, IHF-A):

ANALOG IN: 86 dB(IHF–A weighted)

Frequency response:

20 Hz to 20 kHz: ±1 dB

Network type:

Conforming to IEEE 802.11a/b/g/n

Used frequency range:

2.4 GHz, 5 GHz

Operating temperature:

41 °F - 95 °F (5 °C - 35 °C)

Power supply:

AC 120 V, 60 Hz (for North America)

AC 220 - 240 V, 50/60 Hz (for Europe)

Power consumption:

60 W

Power consumption in Network Standby mode:

4.5W

Power consumption in Deep Standby mode:

0.3 W
