Rear panel

Name Rear small M40

FM antenna terminal (ANTENNA) (for continental model only)
DAB/FM antenna terminal (ANTENNA) (for RCD-M40DAB only)

Used to connect FM antenna or DAB/FM antenna. link

AC inlet (AC IN)

Used to connect the supplied power cord. link

Analog audio connectors (ANALOG IN)

Used to connect devices equipped with analog audio connectors. link

Digital audio connector (DIGITAL IN)

Used to connect devices equipped with digital audio connectors. link

Subwoofer connector (SUBWOOFER OUT)

Used to connect a subwoofer with a built-in amplifier. link

Speaker terminals (SPEAKERS)

Used to connect speakers. link
